Sd.Kfz. 4/1 Panzerwerfer 42 WWII
1/72 scale WWII military VEHICLE plastic model kit
Roden 712
RELEASED JUNE 2011
Number of parts: --
Paint: Unpainted, Unassembled. The kit does not include paints or glue.
During the night of July 14th, 1941, less than a month into the Eastern Campaign, German troops near the Soviet city of Orsha encountered a frightening new weapon that looked like a blazing whirlwind tearing through everything in its path. This was the first combat use of multiple rocket launch, from the BM-13, more widely known as the "Katyusha". Strangely enough, the German army also had comparable weapons before the war began, developed by the engineer Rudolf Nebel, who carried out his first rocket weapon experiments during WWI. The 15cm Nb.W.41 rocket launcher had been part of the Wehrmacht's arsenal for several years. Mounted on a standard 37mm PAK36 gun chassis, it was a six-barrel launcher of 158.5 mm caliber. After capturing a Soviet BM-13 on a ZIS-6 truck chassis, the German high command decided to consider building similar weapons. Its main strength would lie in mobility and in protecting the firing crew under battlefield conditions, meaning the mobile chassis had to be armored. The military selected the well-known Opel Maultier half-track, which had already shown its worth on the rough roads of the Eastern Front.
The prototype appeared in early 1943 and was conceived at the same time as a vehicle carrying a ten-barrel rocket launcher and as an ammunition transporter for it (since a full set of rockets took up considerable space, the firing vehicle carried only 10 extra rounds). The transporter could hold up to thirty rounds for the launcher. The Opel Maultier chassis was topped with an armored body of varying thickness on all sides, and the launcher sat at the rear of the body, able to fire through a 270-degree horizontal arc.
Unlike the Soviet BM-13, the crew did not have to leave the vehicle to fire the rockets; they simply stayed protected inside the body. If needed, the four-man crew could leave quickly through the rear door, and while the vehicle was moving, the driver looked out through narrow openings in the front armored shield.
The gunner, seated on a movable seat directly beneath the launcher, operated the firing. The vehicle commander doubled as radio operator, while two other men drove the vehicle and loaded the launcher. In combat, the armored vehicle, officially named Sd.Kfz. 4/1 Panzerwerfer 42, could defend itself against enemy infantry with its 7.92mm caliber MG-34 machine gun.
Differing from earlier Soviet salvo systems, the Germans could markedly improve the accuracy and concentration of fire from the Sd.Kfz.4/1 Panzerwerfer 42, because the rocket exhaust nozzles were angled relative to the longitudinal axis. During firing, the powder propellant spun the projectile, and this rotation around its own axis made its flight more stable.
The Sd.Kfz.4/1 Panzerwerfer 42 first saw action in April 1943, coming as a very unpleasant surprise to the Soviet Army. Compared with the BM-13, the German salvo system fired fewer rounds in a given time, but its effectiveness was far greater. Captured during the Battle of Kursk, a Sd.Kfz. 4/1 Panzerwerfer 42 was immediately taken to Moscow so that leading Soviet engineers could study its rocket firing systems. This data proved useful in developing a successor to the BM-13, the large caliber BM-24 system. Soviet soldiers nicknamed this somewhat awkward vehicle "Vanyusha" (by analogy with the BM-13 "Katyusha").
In total, German factories produced about 300 examples of the Sd.Kfz. 4/1 Panzerwerfer 42 and more than 250 Munitionskraftwagen ammunition transporters for the Sd.Kfz.4/1 during 1943-1944. Next to several thousand Soviet BM-13 and BM-24 "Stalin Organs", this is a fairly small figure, and the Sd.Kfz.4/1 Panzerwerfer 42 certainly did not change the course of the war, yet its many technical innovations secure it a place in the history of twentieth-century rocket weapons.
Technical Specifications
Overall length
6145mm
Overall width
2240mm
Overall height
2500mm
Maximum speed
40km/h
Armor
8-10mm
Range
130km
Crew
4 men
Armament
10 PC 158mm, MG34 or MG32 machine gun
