Reconnaissance drone US Army RQ-7B UAV 1/35 academy 12117

Reconnaissance drone US Army RQ-7B UAV
1/35
Academy AC12117

Manufacturer: Academy
Scale: 1/35
Material: Plastic
Paint: Unpainted, Unassembled, Kit do not contain paints and glue.
Condition: New in Box


The RQ-7 Shadow unmanned aerial vehicle (UAV) is used by the United States Army, Marine Corps, Australian Army and Swedish Army for reconnaissance, surveillance, target acquisition and battle damage assessment. Launched from a trailer-mounted pneumatic catapult, it is recovered with the aid of arresting gear similar to jets on an aircraft carrier. Its gimbal-mounted, digitally stabilized, liquid nitrogen-cooled electro-optical/infrared (EO/IR) camera relays video in real time via a C-band line-of-sight data link to the ground control station (GCS).

In the US, the Army's 2nd Battalion, 13th Aviation Regiment at Fort Huachuca, AZ, trains soldiers, Marines, and civilians in the operation and maintenance of the Shadow UAV. The training program is mainly undertaken by civilian instructors.The RQ-7 Shadow 200 unmanned aerial vehicle is of a high-wing, constant chord pusher configuration with a twin-tailboom empennage and an inverted v-tail elerudder. The aircraft is powered by a 38 bhp (28 kW) AR741-1101 Wankel engine designed and manufactured by UAV Engines Ltd in the United KingdomCurrently, the primary payload for the aircraft is the Israeli Aircraft Industries POP300 Plug-in Optical Payload which consists of a forward-looking Infrared camera, a daytime TV camera with a selectable near-infrared filter and a laser pointer.he aircraft has fixed tricycle landing gear. Takeoffs are assisted by a trailer-mounted pneumatic launcher which can accelerate the 375 pound aircraft to 70 knots (130 km/h) in 50 feet (15 m). Landings are guided by a Tactical Automatic Landing System, developed by the Sierra Nevada Corporation, which consists of a ground-based micro-millimeter wavelength radar and a transponder carried on the aircraft.The aircraft is part of a larger system which currently uses the M1152-series of Humvees for ground transport of all ground and air equipment. A Shadow 200 system consists of four aircraft, three of which are transported in the Air Vehicle Transporter (AVT). The fourth is transported in a specially designed storage container to be used as a spare. The AVT also tows the launcher. The AVT Support Vehicle and trailer contain extra equipment to launch and recover the aircraft, such as the Tactical Automatic Landing System. Maintenance equipment for the aircraft is stored in the Maintenance Section Multifunctional (MSM) vehicle and trailer as well as the M1165 MSM Support Vehicle and its associated trailer.

Two Humvee-mounted Ground Control Stations (GCS), also part of the Shadow 200 system, control the aircraft in flight. Each station has an associated Ground Data Terminal (GDT), which takes commands generated by the GCS and modulates them into radio waves received by the aircraft in flight. The GDT receives video imagery from the payload, as well as telemetry from the aircraft, and sends this information to the GCS. A trailer, towed by the M1165 GCS support vehicle, carries the GDT and houses a 10 kW Tactical Quiet Generator to provide power for its associated GCS. The Shadow 200 system also includes a Portable Ground Control Station (PGCS) and Portable Ground Data Terminal (PGDT), which are stripped-down versions of the GCS and GDT designed as a backup to the two GCSs.
