Yakovlev Yak-9DD Soviet fighter 1/48 MODELSVIT 4804

Yakovlev Yak-9DD Soviet fighter

1/72  fighter aircraft

ModelSvit MSVIT4804

Manufacturer: ModelSvit (Ukraine)

Scale: 1/72

Material: Plastic

Paint: Unpainted, Unassembled, Kit do not contain paints and glue.

Condition: New in Box

Length model, mm: 118

Wing span, mm: 135

The complete set includes:

86 plastic parts

decal (sticker)

1 frame is made of transparent plastic (canopy)

scheme for painting model

detailed instruction in Russian and English languages.

Yak-9

An airworthy replica of Yak-9U (Yak-9UM) at Reno

Role

Fighter

Manufacturer

Yakovlev OKB

Designer

Alexander Sergeevich Yakovlev

First flight

Summer 1942

Introduction

October 1942

Primary user

Soviet Air Force

Produced

1942–1948

Number built

16,769

Developed from

Yak-1

The Yak-9 represented further development of the successful Yakovlev Yak-7 fighter, a production version of the lightened Yak-7DI, taking full advantage of the combat experience with its predecessor. Greater availability of duralumin allowed for lighter construction which in turn permitted a number of modifications to the basic design.

Yak-9 variants carried two different wings, five different engines, six different fuel tank combinations and seven types of armament configurations. In December 1943, it became possible to install the more powerful M-107 engine on a new Yak-9U airframe: the engine mounting was new with individual faired exhaust pipes; fuselage structure and wings were made of metal and the whole aircraft was covered with a Bakelite skin .[5] Fuel capacity was increased to 400 l (106 US gal). In order to re-balance the model, the wing was repositioned four inches forward and in order to improve pitch control, the horizontal tail surfaces were slightly reduced.[6] The rear part of the canopy was lengthened and the antenna cable was moved inside it. Usual armament was a 20 mm (0.79 in) ShVAK cannon with 120 rounds firing through a hollow propeller shaft and a 12.7 mm (0.50 in) UBSmachine gun with 170 rounds.

The State trials took place from January to April 1944. They revealed a clear superiority in top speed over all other fighters in service on the Eastern front, up to 6,000 m (19,685 ft). The aircraft was simple to fly and stable. Unfortunately, the problems with the M-107A engine and moreover all the M-105 variants from which it derived, persisted:power plant overheating, oil leaks, loss of pressure in climbs, intense vibrations, burning out sparkplugs and a short engine life. Despite these defects, the Yak.9U/VK-107 was ordered into production in April 1944, with 1,134 machines produced by December 1944.[7]
