Polikarpov I-185 Soviet fighter
1/72 scale plastic model kit of a military fighter aircraft
Art Model 7206
Finish: supplied unpainted and unassembled; paints and glue are not included in the kit.
Designed in 1940, the Polikarpov I-185 was a Soviet fighter that was flown with three separate engines, yet each one was either not yet mature enough for operational service or its full output had already been allocated to other fighters in production. The I-185 programme was terminated on 27 January 1943, after yet another failure of the preferred 2,000 hp (1,500 kW) Shvetsov M-71 radial. Although it grew out of the I-180, which in turn was a derivative of the I-16, the I-185, drawn up in early 1940, was essentially a fresh design. Its monocoque fuselage, likewise formed from 'shpon' moulded birch plywood with an integral fin, was noticeably longer than the I-180's. The two-spar, all-metal wing was smaller and slimmer than the I-180's, almost as thin as the Supermarine Spitfire's, measuring 13% at the root and narrowing to 8% at the tip. Using a NACA-230 profile and duralumin skinning, the wing carried pneumatically actuated split flaps and leading-edge slats, with the outer panels set at 3° dihedral. Fabric-covered control surfaces were framed in duralumin. Protected fuel tanks of 540 litres (119 imp gal; 143 US gal) sat between the centre-section spars. The aircraft used a conventional undercarriage with a retractable tailwheel. The unproven 1,492 kW (2,000 hp) 18-cylinder two-row Tumansky M-90 radial was mounted on welded steel tubes and fitted with a ducted spinner to aid cooling, with air exhausted through gills as on the I-180 to add some thrust. Synchronised armament in the fuselage comprised two 7.62 mm (0.300 in) ShKAS machine guns and two 12.7 mm (0.50 in) Berezin UBS machine guns, and a 500 kg (1,100 lb) bomb could be carried under overload conditions. The first prototype was finished in May 1940, but the sole available M-90 could not generate enough power for take-off. The prototype was then re-fitted with another experimental engine, the 895 kW (1,200 hp) Shvetsov M-81 radial, which still lacked sufficient power for flight trials. The I-185 (M-81) finally flew on 11 January 1941, but it was decided not to waste further development effort and to wait for a stronger engine, a fortunate choice as the M-81 was cancelled in May 1941. Following a favourable report from the NII VVS (Naoochno-Issledovatel'skiy Institoot Voyenno-Vozdooshnykh Seel, Air Force Scientific Test Institute) in early 1942, preparations for putting the I-185 (M-71) into production began. A production standard setter (etalon) aircraft was completed in April 1942 with a redesigned engine cowling. Its gross weight rose by 144 kg (317 lb) over the earlier prototypes, yet the drag reduction from the new cowling was significant and the top speed reached 650 km/h (400 mph) at 5000 metres. It went through manufacturer's trials between June and October and was submitted for State acceptance testing on 18 November. Flight testing was halted, however, by the need to replace the engine between 17 December 1942 and 26 January 1943. The new engine failed the following day and the aircraft crashed on 27 January. Flight tests were ordered to continue with the original prototypes to verify range figures, but the first prototype crashed on 5 April, killing the pilot as he attempted a dead-stick landing.
Polikarpov I-185
Side view of the I-185 with an M-71 engine
Role
Fighter
National origin
Soviet Union
Manufacturer
Polikarpov
First flight
11 January 1941
Status
Cancelled
Number built
4
Developed from
Polikarpov I-180
United States · Airmail with tracking · delivery ~14 days.
Change the country in the shipping box above.
| Box weight (products) | Price |
| 0.00 lb – 0.49 lb | $8.90 |
| 0.49 lb – 0.97 lb | $12.99 |
| 0.97 lb – 1.94 lb | $19.99 |
| 1.94 lb – 220.46 lb | $22.99 |
| Order over $150.00 | FREE |
This product weighs 0.21 lb.
